Gigabyte A320M HD3 User Manual

1-2 ProductSpecications
CPU  AM4 Socket:
- AMD Ryzen
™
processor
- AMD 7th Generation A-series/Athlon
™
processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset  AMD A320
Memory  2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
 Dual channel memory architecture
 Support for DDR4 2667
(Note 1)
/2400/2133 MHz memory modules
 Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in
non-ECC mode)
 Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
 Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
 Integrated Graphics Processor:
- 1 x D-Sub port
(Note 2)
, supporting a maximum resolution of 1920x1200@60 Hz
- 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
* The DVI-D port does not support D-Sub connection by adapter.
- 1 x DisplayPort port
(Note 2)
, supporting a maximum resolution of 5120x2880@60 Hz
* Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
* Support for HDMI 1.4 version.
 Support for up to 3 displays at the same time
 Maximum shared memory of 2 GB
Audio  Realtek
®
ALC887 codec
 High Denition Audio
 2/4/5.1/7.1-channel
* To congure 7.1-channel audio, you need to open the audio software and select Device
advanced settings > Playback Device to change the default setting rst. Please visit
GIGABYTE's website for details on conguring the audio software.
 Support for S/PDIF Out
LAN  Realtek
®
GbE LAN chip (1000 Mbit/ 100 Mbit)
Expansion Slots  1 x PCI Express x16 slot, running at x16 (PCIEX16)
(Note 1)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
 2 x PCI Express x1 slots
(The PCI Express x1 slot conforms to PCI Express 2.0 standard.)
 1 x PCI slot
Storage Interface  1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2
(Note 3)
SSD support)
 4 x SATA 6Gb/s connectors
 Support for RAID 0, RAID 1, and RAID 10
* Refer to "1-7 Internal Connectors," for the installation notices for the M.2 connector.
(Note 1) Actual support may vary by CPU.
(Note 2) Simultaneous output for D-Sub and DisplayPort is not supported.
(Note 3) Supports only M.2 SATA SSDs when using an AMD 7th Generation A-series or Athlon
™
processor.
- 6 -

Gigabyte A320M HD3 Specifications

General

Brand	Gigabyte
Model	A320M HD3
Category	Motherboard
Language	English
