Gigabyte B365M GAMING HD User Manual

Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 1 x system fan header
 4 x SATA 6Gb/s connectors
 1 x M.2 Socket 3 connector
 1 x front panel header
 1 x front panel audio header
 1 x USB 3.1 Gen 1 header
 2 x USB 2.0/1.1 headers
 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S
module only)
 1 x serial port header
 1 x Clear CMOS jumper
Back Panel
Connectors
 1 x PS/2 mouse port
 1 x PS/2 keyboard port
 1 x D-Sub port
 1 x HDMI port
 4 x USB 3.1 Gen 1 ports
 2 x USB 2.0/1.1 ports
 1xRJ-45port
 3 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Overheating warning
 Fan fail warning
 Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install.
BIOS  1x128Mbitash
 Use of licensed AMI UEFI BIOS
 PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features  Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported
functionsofeachapplicationmayalsovarydependingonmotherboardspecications.
- @BIOS
- AutoGreen
- Cloud Station
- EasyTune
- EasyRAID
- Fast Boot
- Game Boost
- ON/OFF Charge
- Platform Power Management
- 7 -

Gigabyte B365M GAMING HD Specifications

General

Form Factor	Micro ATX
Chipset	Intel B365
CPU Socket	LGA 1151
Memory Type	DDR4
Memory Slots	2
Max Memory	32 GB
Memory Speed	2666/2400/2133 MHz
PCIe x16 Slots	1
PCIe x1 Slots	2
SATA 6Gb/s Ports	6
M.2 Slots	1
USB 3.1 Gen1 Ports	6
USB 2.0 Ports	6
Audio	Realtek ALC887
LAN	Realtek GbE LAN chip (10/100/1000 Mbit)
RAID Support	Yes
