Gigabyte B450M DS3H User Manual

1-2 ProductSpecications
CPU  AM4 Socket:
- AMDRyzen
™
2nd Generation processors
- AMDRyzen
™
withRadeon
™
Vega Graphics processors
- AMDRyzen
™
1st Generation processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset  AMD B450
Memory  4xDDR4DIMMsocketssupportingupto64GBofsystemmemory
 Dual channel memory architecture
 SupportforDDR42933/2667/2400/2133MHzmemorymodules
 Support forECCUn-bufferedDIMM1Rx8/2Rx8 memorymodules(operatein
non-ECC mode)
 Supportfornon-ECCUn-bufferedDIMM1Rx8/2Rx8/1Rx16memorymodules
 SupportforExtremeMemoryProle(XMP)memorymodules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
 Integrated Graphics Processor:
 - 1xDVI-Dport,supportingamaximumresolutionof1920x1200@60Hz
* The DVI-D port does not support D-Sub connection by adapter.
- 1xHDMIport,supportingamaximumresolutionof4096x2160@60Hz
(Note)
* Support for HDMI 2.0 version and HDCP 2.2.
(Note)
 Maximum shared memory of 2 GB
Audio  Realtek
®
ALC887 codec
 HighDenitionAudio
 2/4/5.1/7.1-channel
* Tocongure7.1-channelaudio,youhavetouseanHDfrontpanelaudiomodule
and enable the multi-channel audio feature through the audio driver.
 Support for S/PDIF Out
LAN  Realtek
®
GbE LAN chip (10/100/1000 Mbit)
Expansion Slots  1 x PCI Express x16 slot, running at x16 (PCIEX16)
(Note)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
 1 x PCI Express x16 slot, running at x4 (PCIEX4)
 1 x PCI Express x1 slot
(The PCIEX4 and PCI Express x1 slots conform to PCI Express 2.0 standard.)
Multi-Graphics
Technology
 Support for AMD Quad-GPU CrossFire
™
and 2-Way AMD CrossFire
™
technologies
Storage Interface  1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe 3.0 x4/x2 SSD support)
 4 x SATA 6Gb/s connectors
 SupportforRAID0,RAID1,andRAID10
* Referto"1-7InternalConnectors,"fortheinstallationnoticesfortheM.2andSATA
connectors.
(Note) Actual support may vary by CPU.
- 6 -

Gigabyte B450M DS3H Specifications

General

Memory channels	Dual-channel
Memory slots type	DIMM
Unbuffered memory	Yes
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200 MHz
Supported memory module capacities	4GB, 8GB, 16GB
HDD size	2.5/3.5 \
Registered	No
Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Athlon, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
PCI Express x1 slots	1
PCI Express x16 slots	2
Supported storage drive types	HDD & SSD
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	256 Mbit
System Management BIOS (SMBIOS) version	2.7
Number of Parallel ATA connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Component for	PC
Motherboard chipset	AMD B450
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10, Windows 7
Bundled software	Norton Internet Security (OEM version) cFosSpeed
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	215 mm
Width	244 mm
