1-7 Internal Connectors

Read the following guidelines before connecting external devices:

• First make sure your devices are compliant with the connectors you wish to connect.

• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power

cord from the power outlet to prevent damage to the devices.

• After installing the device and before turning on the computer, make sure the device cable has

been securely attached to the connector on the motherboard.

1) ATX_12V_2X4

2) ATX

3) CPU_FAN

4) SYS_FAN

5) LED_C

6) M2M_PCH

7) SATA3 0/1/2/3/4/5

8) F_PANEL

9) F_AUDIO

10) F_U32

11) F_USB1/F_USB2

12) COM

13) SPI_TPM

14) CLR_CMOS

15) BAT

1113129
