Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 1 x system fan header
 1 x RGB LED strip header
 6 x SATA 6Gb/s connectors
 1 x M.2 Socket 3 connector
 1 x front panel header
 1 x front panel audio header
 1 x USB 3.2 Gen 1 header
 2 x USB 2.0/1.1 headers
 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI
2.0 module only)
 1 x serial port header
 1 x Clear CMOS jumper
Back Panel
Connectors
 1 x PS/2 mouse port
 1 x PS/2 keyboard port
 1 x D-Sub port
 1 x DVI-D port
 4 x USB 3.2 Gen 1 ports
 2 x USB 2.0/1.1 ports
 1 x RJ-45 port
 3 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Overheating warning
 Fan fail warning
 Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you
install.
BIOS  1 x 128 Mbit ash
 Use of licensed AMI UEFI BIOS
 PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features  Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported
functions of each application may also vary depending on motherboard specications.
- @BIOS
- Ambient LED
- EasyTune
- Fast Boot
- Game Boost
- ON/OFF Charge
- Smart Backup
- System Information Viewer
- 7 -

Gigabyte B460M D2V Specifications

General

Bundled software	Norton Internet Security (OEM) Realtek 8118 Gaming LAN bandwidth Control Utility
Audio chip	Realtek ALC887
Component for	PC
Motherboard chipset	Intel B460
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Motherboard chipset family	Intel
Windows operating systems supported	Windows 10 x64
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	128 Mbit
Clear CMOS jumper	Yes
System Management BIOS (SMBIOS) version	2.7
HDMI ports quantity	0
PS/2 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Number of SATA III connectors	6
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	SATA III
Wi-Fi	No
Ethernet interface type	Gigabit Ethernet
Maximum resolution	1920 x 1200 pixels
Maximum graphics card memory	512 MB
Parallel processing technology support	Not supported
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666, 2933 MHz
Processor socket	LGA 1200 (Socket H5)
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium

Weight and Dimensions

Depth	185 mm
Width	226 mm
