Gigabyte B550 AORUS MASTER User Manual

1-2 Product Specications
CPU  AMD Socket AM4, support for:
3rd Generation AMD Ryzen
™
processors/
New Generation AMD Ryzen
™
with Radeon
™
Graphics processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset  AMD B550
Memory  4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)
of system memory
 Support for DDR4 3200/2933/2667/2400/2133 MHz memory modules
 Dual channel memory architecture
 Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
 Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
 Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
 Integrated in the New Generation AMD Ryzen
™
with Radeon
™
Graphics processors:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.1 version, HDCP 2.3, and HDR.
 Maximum shared memory of 16 GB
Audio  Realtek
®
ALC1220-VB codec
* The back panel line out jack supports DSD audio.
 Support for DTS:X
®
Ultra
 High Denition Audio
 2/4/5.1/7.1-channel
 Support for S/PDIF Out
LAN  Realtek
®
2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)
Wireless
Communication
Module
 Intel
®
Wi-Fi 6 AX200
- WIFI a, b, g, n, ac with wave 2 features, ax, supporting 2.4/5 GHz Dual-Band
- BLUETOOTH 5
- Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
* Actual data rate may vary depending on environment and equipment.
Expansion Slots  1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
- 3rd Generation AMD Ryzen
™
processors support PCIe 4.0 x16 mode
- New Generation AMD Ryzen
™
with Radeon
™
Graphics processors support
PCIe 3.0 x16 mode
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
* The PCIEX16 slot shares bandwidth with the M2B_CPU and M2C_CPU connectors.
The PCIEX16 slot operates at up to x8 mode when a device is installed in the
M2B_CPU or M2C_CPU connector.
 2 x PCI Express x16 slots (PCIEX4_1/PCIEX4_2), integrated in the Chipset:
- Supporting PCIe 3.0 x4 mode
* The PCIEX4_2 slot shares bandwidth with the SATA3 4, 5 connectors. The PCIEX4_2
slot operates at up to x2 mode when a device is installed in the SATA3 4 or SATA3 5
connector.
- 7 -

Gigabyte B550 AORUS MASTER Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 3rd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors	1
ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200 MHz
Audio chip	Realtek ALC1220-VB
Component for	PC
Motherboard chipset	AMD B550
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64
RAID levels	0, 1, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	SATA III
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Ethernet interface type	2.5 Gigabit Ethernet
Maximum resolution	4096 x 2160 pixels
Maximum graphics card memory	16000 MB
Parallel processing technology support	-
DVI-D ports quantity	0
WiFi-AP antenna jack	2
USB 2.0 ports quantity	6
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	5
Number of M.2 (M) slots	3
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
Desktop Management Interface (DMI) version	2.7
Cables included	SATA
Bundled software	Norton Internet Security (OEM) XSplit Gamecaster + Broadcaster Realtek 8125 Gaming LAN Bandwidth Control Utility
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	244 mm
Width	305 mm
