Gigabyte G27F 2 User Manual

- 17 -
Gaming Monitor User Guide
USING THE DEVICE
Turning the Power On/O
Power On
1. Connect one end of the power cable to the AC IN jack at the rear of
the monitor.
2. Connect other end of the the power cable to a power outlet.
3. Press the Control button to turn on the monitor. The Power LED will
light in white, indicating the monitor is ready to use.
Note: If no signal, the monitor will show No Signal notication for a while.
Then, the monitor will go to power saving mode and the Power LED lights
white and starts blinking with a period of one second.
Power O
Press the Control button for 2 seconds to turn o the monitor.
Note: When the Main menu appears on the screen, you can also turn o the
monitor by moving the Control button down ( ). Refer to page 21.

Gigabyte G27F 2 Specifications

General

DDC/CI	Yes
Color gamut	95 %
Pixel pitch	0.3108 x 0.3108 mm
Screen shape	Flat
Backlight type	Edge LED
Display diagonal	27 \
Display technology	LED
Native aspect ratio	-
Maximum refresh rate	170 Hz
sRGB coverage (typical)	130 %
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.6 cm
Display brightness (typical)	400 cd/m²
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Number of upstream ports	1
Input current	3.42 A
AC input voltage	100 - 240 V
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
AC adapter output voltage	19 V
Power consumption (standby)	0.5 W
Power consumption (typical)	21 W
Cables included	AC, HDMI, USB
Tilt angle range	-5 - 20 °
Height adjustment	130 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Product color	Black
Market positioning	Gaming
Package type	Box

Weight and Dimensions

Depth (with stand)	193.63 mm
Width (with stand)	615.11 mm
Height (with stand)	535.66 mm
Weight (with stand)	5200 g
Depth (without stand)	42.21 mm
Height (without stand)	367.35 mm
Weight (without stand)	3500 g
