Gigabyte G27FC A User Manual

LCD Monitor User's Manual
-
12
-
INTRODUCTION
Unpacking
1. Open the upper cover of the packaging box. Then observe the unpacking
instruction attached on the inner cover. Making sure the box is in the
correct orientation, carefully lay the box on the stable surfacepen.
2. Open the inner cover. Grab the EPS foam assembly (through the openings) to
pull it out of the box.

Gigabyte G27FC A Specifications

General

HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Built-in USB hub	Yes
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB Type-A downstream ports quantity	2
Package type	Box
Package depth	248 mm
Package width	700 mm
Package height	481 mm
Package weight	8900 g
Built-in camera	No
RMS rated power	2 W
Cables included	AC, DisplayPort, HDMI, USB
Product color	Black
Market positioning	Gaming
AC input voltage	100 - 240 V
Energy efficiency scale	A to G
Power consumption (max)	60 W
Power consumption (off)	0.3 W
Power consumption (typical)	- W
Power consumption (PowerSave)	0.5 W
Panel type	VA
Color depth	8 bit
Color gamut	91 %
Pixel pitch	0.3114 x 0.3114 mm
Backlight type	Edge LED
Display diagonal	27 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	170 Hz
Response time (fast)	1 ms
Supported video modes	1080p
Screen curvature rating	1500R
Viewable size, vertical	336.31 mm
sRGB coverage (typical)	127 %
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	597.88 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm

Weight and Dimensions

Depth (with stand)	203 mm
Width (with stand)	610.3 mm
Height (with stand)	531 mm
Weight (with stand)	6400 g
Depth (without stand)	84.5 mm
Height (without stand)	367.4 mm
