Gigabyte G27QC User Manual

LCD Monitor User's Manual
-
25
-
USING THE DEVICE
Turning the Power On/O
Make sure the power switch next to the AC power input jack is switched to ON.
Power On
1. Connect one end of the power cable to the AC IN jack at the rear of the monitor.
2. Connect other end of the the power cable to a power outlet.
3. Press the Control button to turn on the monitor. The Power LED will light in
white, indicating the monitor is ready to use.
Power O
Press the Control button for 2 seconds to turn o the monitor.
Note: When the Main menu appears on the screen, you can also turn o the monitor by
moving the Control button down ( ). Refer to page 28.

Gigabyte G27QC Specifications

General

Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Panel type	VA
Color depth	8 bit
Pixel pitch	0.2331 x 0.2331 mm
Backlight type	Edge LED
Display surface	Matt
Display diagonal	27 \
Screen curvature	1500 mm
Display technology	LED
Native aspect ratio	16:9
Supported video modes	1440p
Screen curvature rating	1500R
Viewable size, vertical	335.66 mm
sRGB coverage (typical)	120 %
Contrast ratio (dynamic)	12000000:1
Contrast ratio (typical)	3000:1
Display number of colors	-
Viewable size, horizontal	596.74 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	2560 x 1440
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.4
RMS rated power	4 W
Package type	Box
Package depth	248 mm
Package width	700 mm
Package height	481 mm
Package weight	8900 g
Cables included	AC, DisplayPort, USB
AC input voltage	100 - 220 V
Energy efficiency scale	A to G
Power consumption (off)	0.2 W
Power consumption (standby)	- W
Power consumption (typical)	70 W
Power consumption (PowerSave)	0.3 W
Product color	Black
Market positioning	Gaming

Weight and Dimensions

Depth (with stand)	203 mm
Width (with stand)	610.3 mm
Height (with stand)	531 mm
Weight (with stand)	- g
Depth (without stand)	84.5 mm
Height (without stand)	367.4 mm
Weight (without stand)	6400 g
