- 6 -
GA-8I915PC Duo Motherboard Layout
KB_MS
ATX_12V
CPU_FAN
LGA775
COMA
LPT
DDRII1
DDR1
DDRII2
DDR2
ATX
GA-8I915PC Duo
R_USB
IR
SATA0
SATA2
SATA1
PWR_LED
USB
LAN
BAT
CD_IN
F_AUDIO
Intel 915P
AUDIO1
ICH6
BIOS
PCI2
PCI3
SYS_FAN
SATA3
FDD
F_PANEL
CLR_CMOS
PCIE_16
PCIE_1
PCI1
F_USB1
F_USB2
IT8712
CODEC
AUDIO2
IDE1
Marvell
8001
PCIE_2
COMB
SPDIF_IO
CI
