- 7 -
GA-8I945GZME-RH Motherboard Layout
KB_MS
COMA
LPT
CPU_FAN
ATX_12V
LGA775
FDD
COMB
CI
PWR_LED
PCI3
F_USB2
F_PANEL
F_USB1
CODEC
HDA_SUR
CD_IN
SATAII0
IDE
BIOS
SYS _FAN
ICH7
PCI2
IT8718
SPDIF_IO
PCIE_16
GA-8I945GZME-RH
ATX
BAT
F_AUDIO
VGA
DDRII1
Intel 945GZ
PCI1
CLR_CMOS
USB_LAN
AUDIO
R_USB
DDRII2
Marvell
8001
SATAII3
SATAII2
SATAII1
