1-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has been
securely attached to the connector on the motherboard.
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN
5) SATA3 0/1/2/3
6) F_USB30
7) F_USB1/F_USB2
8) F_PANEL
9) F_AUDIO
10) SPDIF_O
11) TPM
12) CLR_CMOS
13) BAT
1 3
2
7
4
13
812109 11
6
5
- 12 -
