Gigabyte GA-H310MSTX-HD3-CM User Manual

& Platform Power Management
Enables or disables the Active State Power Management function (ASPM). (Default: Disabled)
& PEG ASPM
 Allowsyou toconguretheASPMmodefor thedevice connectedtothe CPUPEGbus. Thisitemis
congurableonlywhenPlatform Power Management is set to Enabled. (Default: Disabled)
& PCH ASPM
 AllowsyoutoconguretheASPMmodeforthedeviceconnectedtoChipset'sPCIExpressbus.Thisitem
iscongurableonlywhenPlatform Power Management is set to Enabled. (Default: Disabled)
& DMI ASPM
 AllowsyoutoconguretheASPMmodeforbothCPUsideandChipsetsideoftheDMIlink.Thisitemis
congurableonlywhenPlatform Power Management is set to Enabled. (Default: Disabled)
& AC BACK
Determines the state of the system after the return of power from an AC power loss.
Memory The system returns to its last known awake state upon the return of the AC power.
Always On The system is turned on upon the return of the AC power.
Always Off The system stays off upon the return of the AC power. (Default)
2-8 Power
& IOAPIC 24-119 Entries
Enables or disables this function. (Default: Enabled)
& Aperture Size
Allows you to allocate the memory size of the onboard graphics. Options are: 128MB~2048MB. (Default:
256MB)
- 33 -
