- 35 - BIOS Setup
2-3 MB Intelligent Tweaker(M.I.T.)
• Whether the system will work stably with the overclock/overvoltage settings you made is
dependent on your overall system configurations. Incorrectly doing overclock/overvoltage
may result in damage to CPU, chipset, or memory and reduce the useful life of these
components. This page is for advanced users only and we recommend you not to alter the
default settings to prevent system instability or other unexpected results. (Inadequately alter
ing the settings may result in system's failure to boot. If this occurs, clear the CMOS values
and reset the board to default values.)
• When the System Voltage Optimized item blinks in red, it is recommended that you set
the System Voltage Control item to Auto to optimize the system voltage settings.
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
MB Intelligent Tweaker(M.I.T.)
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
(Note) This item is present only if you install a CPU that supports this feature.
Advanced Clock Calibration [Press Enter]
CPU Frequency [200]
HT Link Frequency [Auto]
PCIE Clock [100]
CPU Clock Ratio [Auto]
CPU NorthBridge Freq.
(Note)
[Auto]
Robust Graphics Booster [Disabled]
x VGA Core Clock +1%
DRAM Configuration [Press Enter]
********
System Voltage Optimized
********
System Voltage Control [Auto]
x DDR2 Voltage Control Normal
x Chipset/PCIE Voltage Normal
x HT-Link Voltage Normal
x CPU NB VID Control
(Note)
Norm=l
x CPU Voltage Control Normal
Normal CPU Vcore 1.2500V
Advanced Clock Calibration
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Advanced Clock Calibration
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
NVIDIA Core Calibration [Disabled]
x Core 0 NVCC Percentage 0%
x Core 1 NVCC Percentage 0%
x Core 2 NVCC Percentage 0%
x Core 3 NVCC Percentage 0%
To Next Page
