Gigabyte GA-MA74GM-S2 User Manual

Hardware Installation - 10 -
1-2 Product Specications
CPU

Support for AM3/AM2+/AM2 processors:
AMD Phenom
™
II processor/ AMD Phenom
™
processor/
AMD Athlon
™
II processor/ AMD Athlon
™
processor/
AMD Sempron
™
processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport Bus

2000 MT/s
Chipset

 North Bridge: AMD 740G


 South Bridge: AMD SB710
Memory

2 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory
(Note 1)

Dual channel memory architecture

Support for DDR2 1066/800/667/533 MHz memory modules

Support for non-ECC memory modules


 (Go to GIGABYTE's website for the latest supported memory speeds and memory modules.)
Onboard Graphics

Integrated in the North Bridge:
- 1 x D-Sub port
- 1 x DVI-D port
(Note 2) (Note 3)
- 1 x HDMI port
j
(Note 3)
Audio
   
Realtek ALC888B codec

HighDenitionAudio

2/4/5.1/7.1-channel
(Note 4)
    
Support for S/PDIF Out

Support for S/PDIF In

Support for CD In
LAN

1 x Realtek RTL 8111D/E chip (10/100/1000 Mbit)
Expansion Slots

1 x PCI Express x16 slot, running at x16

1 x PCI Express x1 slot

2 x PCI slots
Storage Interface

South Bridge:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 10, and JBOD

iTE IT8718 chip:
      - 1xoppydiskdriveconnectorsupportingupto1oppydiskdrive
USB

South Bridge

- Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
j
Only for GA-MA74GM-S2H

Gigabyte GA-MA74GM-S2 Specifications

General

Memory voltage	1.8 V
Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	4
S/PDIF out connector	Yes
Number of SATA connectors	6
Number of EATX power connectors	1
Special features	@BIOS Download Center Q-Flash EasyTune (Note 5) Xpress Install Xpress Recovery2 Virtual Dual BIOS
Controller interface type	iTE IT8718
Headphone outputs	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC888
Motherboard chipset	AMD 740G
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows Vista/XP/ME/9X
RAID levels	0, 1
Bundled software	Norton Internet Security
LAN controller	Realtek RTL8111C
Networking features	10/100/1000 Mbit

Weight and Dimensions

Depth	234 mm
Width	244 mm
