Gigabyte GA-MA790X-UD4P User Manual

GA-MA790X-UD4P Motherboard - 78 -
Create Arrays Manually
To create a new array, press <2> to enter the Define LD window (Figure 4). The Define LD selection
from the Main Menu allows users to begin the process of manually defining the drive elements and
RAID levels for one or multiple disk arrays attached to the AMD SB750 controller.
[ ] Up [] Down [ESC] Exit [Enter] Select
FastBuild (tm) Utility (c) 2008 Advanced Micro Devices, Inc.
[ Keys Available ]
[ Define LD Menu ]
LD No RAID Mode Total Drv Capacity (GB) Status
LD 1 ---- ---- ----- ----
LD 2 ---- ---- ----- ----
LD 3 ---- ---- ----- ----
LD 4 ---- ---- ----- ----
LD 5 ---- ---- ----- ----
LD 6 ---- ---- ----- ----
LD 7 ---- ---- ----- ----
LD 8 ---- ---- ----- ----
LD 9 ---- ---- ----- ----
LD 10 ---- ---- ----- ----
Figure 4
In Figure 4, use the up or down arrow key to move to a logical disk set and press <Enter> to enter the
RAID configuration menu (Figure 5).
Figure 5
[ ] Up [] Down [ESC] Exit [Space] Change [Ctrl-Y] Save [PgUp/Dn] Page Change
FastBuild (tm) Utility (c) 2008 Advanced Micro Devices, Inc.
[ Keys Available ]
[ Define LD Menu ]
LD No RAID Mode Total Drv
LD 1 RAID 0 0
Stripe Block: 64 KB Fast Init: ON
Gigabyte Boundary: ON Cache Mode: WriteThru
[ Drives Assignments ]
Channel:ID Drive Model Capabilities Capacity (GB) Assignment
1:Mas WDC WD800JD-22LSA0 SATA 3G 79.89 N
2:Mas WDC WD800JD-22LSA0 SATA 3G 80.02 N
