Gigabyte GA-P35-DS4 User Manual

GA-P35-DS4 Motherboard - 10 -
English
1-2 Product Specifications
CPU  Support for an Intel
®
Core
TM
2 Extreme processor/
Intel
®
Core
TM
2 Quad processor/Intel
®
Core
TM
2 Duo processor/
Intel
®
Pentium
®
processor Extreme Edition/Intel
®
Pentium
®
D processor/
Intel
®
Pentium
®
4 processor Extreme Edition/Intel
®
Pentium
®
4 processor/
Intel
®
Celeron
®
processor in the LGA 775 package
(Go to GIGABYTE's website for the latest CPU support list.)
 Support for Intel
®
Hyper-Threading Technology
 L2 cache varies with CPU
Front Side Bus  1600 (O.C.)/1333/1066/800 MHz FSB
Chipset  North Bridge: Intel
®
P35 Chipset
 South Bridge: Intel
®
ICH9R
Memory  4 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory
(Note 1)
 Dual channel memory architecture
 Support for DDR2 1200 (O.C.)/1066/800/667 MHz memory modules
(Go to GIGABYTE's website for the latest memory support list.)
Audio  Realtek ALC889A codec
 High Definition Audio
 2/4/5.1/7.1-channel
 Support for DTS (dts NEO:PC)
 Support for S/PDIF In/Out
 Support for CD In
LAN  Realtek 8111B chip (10/100/1000 Mbit)
Expansion Slots  2 x PCI Express x16 slots
(The PCIE_16_1 slot supports x16; the PCIE_16_2 supports x4.)
 3 x PCI Express x1 slots (share with the PCIE_16_2 slot)
(Note 2)
 2 x PCI slots
Storage Interface  South Bridge:
- 6 x SATA 3Gb/s connectors (SATAII0, SATAII1, SATAII2, SATAII3,
SATAII4, SATAII5) supporting up to 6 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10
 GIGABYTE SATA2 chip:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 2 x SATA 3Gb/s connectors (GSATAII0, GSATAII1) supporting up to
2 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, and JBOD
 iTE IT8718 chip:
- 1 x floppy disk drive connector supporting up to 1 floppy disk drive
IEEE 1394  T.I. TSB43AB23 chip
 Up to 3 IEEE 1394a ports (2 on the back panel, 1 via the IEEE 1394 bracket
connected to the internal IEEE 1394 header)

Gigabyte GA-P35-DS4 Specifications

General

Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Number of SATA connectors	8
Floppy disk drive connector	Yes
PS/2 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC889A
Audio output channels	7.1 channels
Motherboard form factor	ATX

Weight and Dimensions

Depth	244 mm
Width	305 mm
