- 8 -
GV-N500 Series Graphics Accelerator
2. Hardware Installation
2.1. Board Layout
DVI-I connector 1
DVI-I Connector 2
SLI Connector
Power Connectors
Mini HDMI Connector
DVI-I
Connector 2
DVI-I
Connector 1
Mini HDMI
Connector
Digital LCD Monitor
Digital LCD Monitor
DVI Output
DVI Output
HDMI TV
GV-N550OC-1GI / GV-N550UD-1GI
