Gigabyte M28U User Manual

- 20 -
Gaming Monitor User Guide
Installing a Wall-Mount Bracket (Optional)
Use only the 100 x 100 mm wall mount kit recommended by the
manufacturer.
1. Place the monitor on the lower EPS foam, with the screen facing
down.
2. While pushing the locking latch forward, slide the stand backward to
release the upper hooks from the mounting slots on the rear of the
monitor. Then remove the stand.
3. Attach the mounting bracket to the mounting holes at the rear of
the monitor. Then use the screws to secure the bracket in place.
DPHDMI-2TYPE-C USB 3.0
HDMI-1
100 mm
100 mm
Note: To mount the monitor on the wall, refer to the installation guide that is
included in the wall-mount bracket kit.

Gigabyte M28U Specifications

General

Headphone out	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.4
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	3
Panel type	SS-IPS
Color depth	8 bit
Color gamut	94 %
Pixel pitch	0.16 x 0.16 mm
Screen shape	Flat
Backlight type	Edge LED
Display diagonal	28 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display technology	LED
Native aspect ratio	16:9
Viewable size diagonal	359.78 mm
Viewable size, vertical	631.928 mm
sRGB coverage (typical)	120 %
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 3840 x 2160
High Dynamic Range (HDR) technology	High Dynamic Range (HDR) 400
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	115 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	- W
AMD FreeSync type	FreeSync Premium Pro
Operating temperature (T-T)	0 - 40 °C
RMS rated power	6 W
Cables included	AC, DisplayPort, HDMI, USB
Package type	Box
Package depth	148 mm
Package width	890 mm
Package height	510 mm
Package weight	9700 g
Product color	Black
Market positioning	Gaming
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	193.6 mm
Width (with stand)	636.5 mm
Height (with stand)	534.2 mm
Weight (with stand)	6930 g
Depth (without stand)	63.1 mm
Height (without stand)	372.3 mm
Weight (without stand)	5180 g
