4
Attach the quick connector end of the spray
hose (G) into the spray holder (E).
Installing the spray holder
Installing the faucet assembly
Insert the spray holder (E) into the installation
hole on the sink and tighten the spray lock nut
(F) onto the spray holder shank.
Installation
2
A
C
1
CAUTION: Always turn off the water supply before
removing an existing faucet or replacing any part of a
faucet. Open the faucet handle to relieve water pressure
and ensure that the water is completely shut off.
Shut off the water supply. Remove the old faucet.
Place the faucet (A) through the mounting holes in
the sink.
Ensure the gasket (H) is on the bottom of the new
faucet (A).
Clean off the mounting surface.
Secure the faucet (A) to the sink using the lock nuts
(C) provided.
NOTE: If the sink is uneven, use silicone under the
gasket (H).
H
G
E
F
