16
4.2 GRASS CATCHER
Before removing the grass catcher put the PTO in neutral and check to make
sure the blade has stopped.
Empty the grass from the catcher. When the catcher is removed the deflector
plate 4 fig.1 shuts automatically.
If the mower is used without the catcher, the deflector plate stays shut and the
grass is evacuated from the right of the machine.
4.3 BLADE
Stop the engine and wait until the blade has stopped completely. Detach the
mower from the tractor and remove the two screws n. 3 fig.1 to take the blade
off. Sharpen or replace the blade as necessary.
4.4 REGISTERING THE BRAKE
If the time needed for the blade of come to a stop is too long, register its brake
as follows:
Tip the mower over so that the front is accessible. Remove cover 1 fig.2 slacken
off nut 2 about a 1/2 turn (anti-clockwise, then replace cover 1.
