Goodwe DNS - Product Introduction; Inverter Parts Identification; Inverter Dimensions

03
1 2 3 4 5
76
8 9 10 11
354mm
147mm
195mm
32.5mm 32.5mm
130mm
433mm
115mm
02 Product Introduction
1. PVInputTerminal 2. DCSwitch 3.
WiFi/4G/LAN/GPRSCommunication
ModulePortorRS485
CommunicationCablePort
4.
DRED/CT/RemoteShut
downCommunication
CablePort
5.
ACOutput
Terminal
6. Indicator
7. LCD 8. Button 9. PETerminal
10. MountingPlate 11. HeatSink
Parts
Dimensions
