11
SEAT ASSEMBLY
Model 991079, 080, 081, 095, 096, 097, 102, 103, 104
Item Part No. Qty Description
1 05717100 2 Ring, Retaining External .500 x .050
2 06425300 2 Washer, Flat Steel .531 x 1.00 x .063
3 04052900 1 Seat, Suspension – with Belt, Light Gray
4 03837800 1 Shaft, 100I Seat Pivot
5 05500901 2 Bushing, Flange .516 x .750 x .625 x .937
6 03933251 1 Seat Plate Weldment
7 06545400 4 Nut, Locking Top Flange .31-18
8 05947000 2 Bolt, Hex .31-18 x .75
9 03918551 1 Pro-Turn 100 Left Hand Top Seat Latch Mount
10 03917951 1 Pro-Turn 100 Right Hand Top Seat Latch Mount
11 08321100 1 Spring, Tension .043 x .44 x 3.31
12 03917751 1 Pro-Turn 100 Seat Latch Weldment
13 06706900 1 Pin, Center .09 x .75 Extended Prong Square Cut
14 06436200 1 Washer, Flat Steel .406 x .812 x .065
15 03930451 1 Pro-Turn 100 Seat Latch Mount Weldment Right Hand
16 03930551 1 Pro-Turn 100 Seat Latch Mount Weldment Left Hand
17 59210400 AR Kit, Armrest Assembly Right Hand
18 59210500 AR Kit, Armrest Assembly Left Hand
19 59208800 AR Kit, Back Cushion, Light Grey
20 59208900 AR Kit, Seat Cushion, Light Grey
21 59208000 AR Kit, Seat Knobs
22 59208100 AR Kit, Seat Back
23 59207900 AR Kit, Seat Slides
24 59207800 AR Kit, Seat Spring and Saddle
