Gravely ZT 34 User Manual

EN - 17
Steering Levers
• Reverse (1) – Pull both steering levers
backward.
• Forward (2) – Push both steering
levers forward.
• Left (3) – Pull left steering lever back
or push right steering lever forward or
a combination of both.
• Right (4) – Pull right steering lever
back or push left steering lever
forward or a combination of both.
NOTE: To stop, return both steering levers to
neutral.
NOTE: The steering levers must be in the
neutral position to start the engine.
NOTE: The parking brake must be
disengaged prior to moving the steering
levers from the neutral position.
Height of Cut
(Figure 5)
1. Press the mower Gravely lift pedal to
raise the deck.
2. Position height of cut selector lever at
the desired setting in the height of cut
bracket.
3. Release mower lift pedal.
Seat Adjustment
Models 915212, 915214, 915232, 915234,
915246
(Figure 6)
Push lever back and slide seat forward or
backward to the desired position. Release
lever to lock seat in position.
Seat Adjustment
Models 915208, 915210, 915244
1. Tip the seat forward. See Tipping Seat
Forward on page 23.
2. Loosen mounting hardware and slide
seat forward or backward to desired
position. Tighten mounting hardware
(figure 9).
3. Tip seat back.
Washout Port
Models 915212, 915214, 915232, 915234,
915246
(Figure 7)
NOTICE: Wash the underside of the mower
after each use to prevent grass buildup and
improve mulch action and clipping dispersal.
1
2
3
4
Figure 5
1. Mower Lift Pedal
2. Height of Cut Selector Lever
3. Height of Cut Bracket
2
3
1
WARNING: A broken or
missing deck port can result in
exposure to harmful thrown
objects or blade contact.
Replace broken or missing
deck port before using unit.
NEVER put your hands or feet
under the mower or through
openings in the mower.
Figure 6

Gravely ZT 34 Specifications

General

Deck Material	Steel
Turning Radius	Zero-turn
Blade Engagement	Electric PTO
Cutting Width	34 in
Warranty	3 years
