Gravely ZT HD 44 User Manual

EN - 34
5. Slowly disconnect lift-assist springs from
spring peg on each side of deck. See
Figure 46.
6. Remove hardware retaining drag links to
frame. See Figure 47.
7. Remove hardware retaining deck lift links
to deck lift brackets. See Figure 48.
8. Remove deck from under unit.
Install Deck
1. Position deck under unit.
See Figure 49.
2. Reinstall drag links to frame with original
hardware.
3. Secure deck lift links to deck lift brackets
with original hardware.
4. Reinstall PTO belt. See Install PTO Belt
on page 30.
5. Reconnect lift-assist springs to spring
pegs.
Figure 46
1. Lift-Assist Spring
2. Spring Peg
1
2
Figure 47
Figure 48
Figure 49

Gravely ZT HD 44 Specifications

General

Engine Brand	Kawasaki
Cutting Width	44 inches
Deck Material	10-gauge steel
Engine Size	726 cc
Cutting Height	1.5 - 4.5 inches
Spindle Material	Aluminum
Seat	High Back
Ground Speed Forward	8 mph
Ground Speed Reverse	4 mph
