Gravely ZT HD 60 User Manual

EN - 34
5. Slowly disconnect lift-assist springs from
spring peg on each side of deck. See
Figure 46.
6. Remove hardware retaining drag links to
frame. See Figure 47.
7. Remove hardware retaining deck lift links
to deck lift brackets. See Figure 48.
8. Remove deck from under unit.
Install Deck
1. Position deck under unit.
See Figure 49.
2. Reinstall drag links to frame with original
hardware.
3. Secure deck lift links to deck lift brackets
with original hardware.
4. Reinstall PTO belt. See Install PTO Belt
on page 30.
5. Reconnect lift-assist springs to spring
pegs.
Figure 46
1. Lift-Assist Spring
2. Spring Peg
1
2
Figure 47
Figure 48
Figure 49

Gravely ZT HD 60 Specifications

General

Engine Brand	Kawasaki
Engine Model	FR730V
Horsepower	24 HP
Engine Displacement	726 cc
Cutting Width	60 inches
Transmission Type	Hydro-Gear ZT-3100
Blade Tip Speed	18, 000 fpm
Ground Speed Reverse	4 mph
Turning Radius	Zero-turn
Seat Type	High Back with Armrests
Cutting Height	1.5 - 5 inches
Warranty	4 years or 500 hours
