Butterfly Series
-
30
-
9. PCB function manual
PCB function manual for butterfly
A. running mode
1. cooling 2.dehumidifying 3.heating 4. auto
B. input parameters
1.indoor ambient temp. T
in
2.evaporator tube temp. T
eva
3.setting temp. T
set
4.condenser tube temp. T
con
C. targets
1.indoor motor
2.stepping motor (swing motor)
3.outdoor motor
4.compressor
5.four-way reversing valve
6.cooling, dehumidifying indicator; running indicator(for birdline, butterfly series)
7.auxiliary electric heater
D. fundamental functions
1.cooling mode
(1)the running conditions and control measures
a. if T
in
T
set
+ 1 , the machine runs at the cooling mode. Compressor and outdoor motor runs,
indoor fan runs at the set fan speed.
b. if T
in
T
set
-1 , the machine stops. Compressor stops first , outdoor motor stops after 15
seconds , indoor motor runs at the set fan speed.
c. if T
set
-1 T
in
T
set
+1 ,keep the previous state.
(2)in this mode, the reversing valve is inactive, the temp. setting range is from 16
to 30 .
(3)Protect function
a. anti-freezing function.
if compressor has run 6 minutes , and detects T
eva
< 0 for continuous 3 minutes, then the
compressor stops, outdoor fan stops after 15 seconds, indoor fan runs at the set fan speed. After
3 minutes later, it will runs at the original state if T
eva
10 .
b. compressor protection
Compressor’s starting interval should be more than 3 minutes no matter in whatever modes
