5HPRYDO3URFHGXUH
Procedure
Steps
c
d
a
b
Remove the screw fixing the electric box.
Remove the electric box.
7.Remove the evaporator
Remove the screw of the pipe clamp.
Remove the pipe clamp.
Remove the screw fixing the evaporator and the
chassis. Adjust the pipe and remove the
evaporator.
evaporator
screw
pipe clamp
electric box
screw
