Gree GMV-120WM/B-F User Manual

GMV DC Inverter VRF
2
2 Product Introduction
Gree Multi VRF Modular System adopts inverter compressor technology. According to change
the displacement of compressor, stepless capacity regulation within range of 10%-100% can be
realized. Various product lineup is provided with capacity range from 72kBtu/h to 360kBtu/h, which
can be widely used in working area and especially applicable to the place with variable load
change. Gree air conditioner is absolutely your best choice.
2.1 Names of Main Parts
Fig.1
NO.
①
②
③
④
⑤
Name
Fan, Motor
Electric Box Assembly
Valve interface
Power cord
through-hole
Communication code
through-hole
2.2 Combinations of Outdoor Units
Model (Single)
GMV-144WM/B-F(U)
GMV-168WM/B-F(U)
GMV-192WM/B-F(U)
Model (Combined)
GMV-72WM/B-F(U)
+ GMV-72WM/B-F(U)
GMV-72WM/B-F(U)
+ GMV-96WM/B-F(U)
GMV-96WM/B-F(U)
+ GMV-96WM/B-F(U)
Model (Single)
GMV-216WM/B-F(U)
GMV-240WM/B-F(U)
GMV-264WM/B-F(U)
Model (Combined)
GMV-96WM/B-F(U)
+ GMV-120WM/B-F(U)
GMV-120WM/B-F(U)
+ GMV-120WM/B-F(U)
GMV-72WM/B-F(U)
+ GMV-96WM/B-F(U)
+ GMV-96WM/B-F(U)
Model (Single)
GMV-288WM/B-F(U)
GMV-312WM/B-F(U)
GMV-336WM/B-F(U)
Model (Combined)
GMV-96WM/B-F(U)
+ GMV-96WM/B-F(U)
+ GMV-96WM/B-F(U)
GMV-96WM/B-F(U)
+ GMV-96WM/B-F(U)
+ GMV-120WM/B-F(U)
GMV-96WM/B-F(U)
+ GMV-120WM/B-F(U)
+ GMV-120WM/B-F(U)
Model (Single)
GMV-360WM/B-F(U)
Model (Combined)
GMV-120WM/B-F(U)
+ GMV-120WM/B-F(U)
+ GMV-120WM/B-F(U)
