Gree GMV-ND56T/B-T User Manual

Multi Variable Air Conditioners Cassette Type Indoor Unit
7
circuit breaker.
Model
Power Supply
Air Switch
Capacity (A)
Minimum
Sectional Area of
Grounding
Wire(mm
2
)
Minimum
Sectional Area
of Power Cord
(mm
2
)
GMV-ND22T/B-T
220~240V-1ph-50Hz
208~230V-1ph-60Hz
6
1
1
GMV-ND28T/B-T
6
1
1
GMV-ND36T/B-T
6
1
1
GMV-ND45T/B-T
6
1
1
GMV-ND50T/B-T
6
1
1
GMV-ND56T/B-T
6
1
1
4 Installation Instructions
4.1 Indoor unit installation
4.1.1 Indoor unit dimension and suspension bolt position
Fig 4.1.1
Below are dimensions of A, B, C, etc. for different models:
Unit: mm/inch
Model
A (mm)
B (mm)
C (mm)
D (mm)
E (mm)
F (mm)
Drainage
Pipe(Outer
Diameter× wall
thickness) (mm)
Outer Diameter of
Connection
Pipe(mm)
Liquid
pipe
Gas pipe
GMV-ND22T/B-T
670
596
592
571
145
240
φ25×2. 5
6.35
9.52
GMV-ND28T/B-T
6.35
9.52
GMV-ND36T/B-T
6.35
12.7
GMV-ND45T/B-T
6.35
12.7
GMV-ND50T/B-T
6.35
12.7
GMV-ND56T/B-T
9.52
15.9
Important: The drilling work and installation of unit must be carried out by qualified personnel.
