Technical Information
Service Manual
Model GWC09QB-A3DNA5E GWC09QB-A3DNB8E
Product Code CB425006500 CB438003801
Power Supply
Rated Voltage V~ 115 115
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity(Min~Max) Btu/h 9000(2764~10918) 9000(2764~10918)
Heating Capacity(Min~Max) Btu/h / /
Cooling Power Input(Min~Max) W 823(350~1270) 823(350~1270)
Heating Power Input(Min~Max) W / /
Cooling Power Current A 10.93 10.93
Heating Power Current A / /
Rated Input W 1270 1270
Rated Current A 11.27 11.27
Air Flow Volume(SH/H/M/L) CFM 318/288/241/171 318/288/241/171
Dehumidifying Volume Pint/h 1.69 1.69
EER (Btu/h)/W 11.05 11.05
COP (Btu/h)/W / /
SEER 16.00 16.00
HSPF / /
Application Area yd
2
14.35-21.53 14.35-21.53
Indoor Unit
Model of indoor unit GWC09QB-A3DNA5E/I GWC09QB-A3DNB8E/I
Indoor Unit Product Code CB425N06500 CB438N03801
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ3 7/8X22 13/16 Φ3 7/8X22 13/16
Fan Motor Cooling Speed(SH/H/M/L) r/min 1350/1200/1050/750 1350/1200/1050/750
Fan Motor Heating Speed(SH/H/M/L) r/min / /
Output of Fan Motor W 20 20
Fan Motor RLA A 0.24 0.24
Fan Motor Capacitor μF 4 4
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/16 Φ3/16
Row-n Gap inch 2-1/16 2-1/16
Coil Length (LXDXW) inch 23X7/8X10 8/16 23X7/8X10 8/16
Swing Motor Model MP24AA MP24AA
Output of Swing Motor W 1.5 1.5
Fuse A 3.15 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 42/38/34/28 42/38/34/28
Sound Power Level(SH/H/M/L) dB (A) 52/49/45/39 52/49/45/39
Dimension (WXHXD) inch 31 1/8X10 13/16X7 7/8 31 1/8X10 13/16X7 7/8
Dimension of Carton Box (LXWXH) inch 34X10 9/16X13 7/8 34X10 9/16X13 7/8
Dimension of Package (LXWXH) inch 34 1/8X10 11/16X14 7/16 34 1/8X10 11/16X14 7/16
Net Weight Ib 20.94 19.84
Gross Weight Ib 25.35 24.25
2. Specications
2.1 Specication Sheet
No. Model Product code Indoor model
Indoor product
code
Outdoor model
Outdoor product
code
1 GWC09QB-A3DNA5E CB425006500 GWC09QB-A3DNA5E/I CB425N06500
GWC09QB-A3DNA6E/O(LC) CB427W04000
2 GWC09QB-A3DNB8E CB438003801 GWC09QB-A3DNB8E/I CB438N03801
3 GWH09QB-A3DNA5E CB425006400 GWH09QB-A3DNA5E/I CB425N06400
GWH09QB-A3DNA6E/O(LCLH) CB427W03900
4 GWH09QB-A3DNB8E CB438003702 GWH09QB-A3DNB8E/I CB438N03702
5 GWH09QB-A3DNB2E CB432006002 GWH09QB-A3DNB2E/I CB432N06002
6 GWH09QB-A3DNC2E CB439006001 GWH09QB-A3DNC2E/I CB439N06001
7 GWC12QC-A3DNA5E CB425006201 GWC12QC-A3DNA5E/I CB425N06201
GWC12QC-A3DNA6E/O(LC) CB427W038008 GWC12QC-A3DNB8E
CB438004001 GWC12QC-A3DNB8E/I
CB438N04001
9 GWC12QC-A3DNC8E CB456002901 GWC12QC-A3DNC8E/I CB456N02901
10 GWC12QC-A3DNA5K CB425007800 GWC12QC-A3DNA5K/I CB425N07800
GWC12QC-A3DNA5K/O(LC) CB425W0780011 GWC12QC-A3DNB2K CB432008900 GWC12QC-A3DNB2K/I CB432N08900
12 GWC12QC-A3DND8K CB459003900 GWC12QC-A3DND8K/I CB459N03900
13 GWH12QC-A3DNA5E CB425006300 GWH12QC-A3DNA5E/I CB425N06300
GWH12QC-A3DNA1D/O(LCLH) CB427W03700
14 GWH12QC-A3DNB2E CB432006102 GWH12QC-A3DNB2E/I CB432N06102
15 GWH12QC-A3DNB8E CB438003902 GWH12QC-A3DNB8E/I CB438N03902
16 GWH12QC-A3DNC8E CB456002400 GWH12QC-A3DNC8E/I CB456N02400
17 GWH12QC-A3DNC2E CB439006201 GWH12QC-A3DNC2E/I CB439N06201
18 GWH12QC-A3DNA5K CB425007900 GWH12QC-A3DNA5K/I CB425N07900
GWH12QC-A3DNA5K/O(LCLH) CB425W07900
19 GWH12QC-A3DNB2K CB432009100 GWH12QC-A3DNB2K/I CB432N09100
20 GWH12QC-A3DNB8K CB438008200 GWH12QC-A3DNB8K/I CB438N08200
21 GWH09QB-A3DNB8K CB438008000 GWH09QB-A3DNB8K/I CB438N08000 GWH09QB-A3DNA5K/O(LCLH) CB425W08200
22 GWC12QC-D3DNC8H CB456003101 GWC12QC-D3DNC8H/I CB456N03101 GWC12QC-D3DNA6H/O CB427W05800
