79
Installation and Maintenance
Service Manual
No.
Description
Part Code
QtyGWH18QD-D3DNA6E/O GWH24QE-D3DNA6E/O
Product Code CB427W02000 CB427W02400
1 Front Grill 01473049 01473049 1
2 Cabinet 01433047P 01433047P 1
3 Axial Flow Fan 10335008 10335008 1
4 Fan Motor 1501506402 1501506402 1
5 Chassis Sub-assy 01700000093P 0280336702P 1
6 Drainage hole Cap 06813401 06813401 3
7 Clapboard Assy 01233153 0123315301 1
8 4-Way Valve Assy 03073366 03073324 1
9 Compressor and Fittings 00105249G 00105249G 1
10 Valve Support Assy 01715010P 01713098P 1
11 Cut off Valve 07133774 07133157 1
12 Cut off Valve Sub-Assy 07133204 07133975 1
13 Right Side Plate 0130509403P 0130509403P 1
14 Valve Cover 22245002 22245002 1
15 Retaining Plate 02115006P 02115006P 1
16 Handle Assy 02113109 02113109 1
17 Wiring Clamp 26115004 26115004 1
18 Temperature Sensor 3900030901 3900030901 1
19 Rear Grill 01473043 01473043 1
20 Condenser Assy 01100200339 01100200347 1
21 Coping 01255005P 01255005P 1
22 Motor Support Sub-Assy 01703154 0170512001 1
23 Condenser Support Plate 01173127 01173415 1
24 Left Side Plate 01305093P 01305093P 1
25 Handle 26233053 26233053 1
26 Electric Box Assy 10000100288 10000100294 1
27 Terminal Board 42010255 4201025501 1
28 Electric Box 20113027 20113027 1
29 Main Board 30138000685 30138000673 1
30 Radiator 49010252 49010252 1
Above data is subject to change without notice.
