6
Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit GWC24QE-D3DNA6E/O(LC) GWH24QE-D3DNA6E/O(LCLH)
Outdoor Unit Product Code CB427W02300 CB427W02400
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO.,LTD
ZHUHAI LANDA COMPRESSOR
CO.,LTD
Compressor Model QXA-B141zF030A QXA-B141zF030A
Compressor Oil 68EP 68EP
Compressor Type Rotary Rotary
Compressor Locked Rotor Amp (L.R.A) A 25.00 25.00
Compressor RLA A 7.20 7.20
Compressor Power Input W 1440 1440
Overload Protector
1NT11L-6233 or KSD115
℃
or
HPC115/95U1
1NT11L-6233 or KSD115
℃
or
HPC115/95U1
Throttling Method Capillary Capillary
Operation temp ºF 60.8~86 60.8~86
Ambient temp (cooling) ºF 0~115 0~115
Ambient temp (heating) ºF / -4~75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/8 Φ3/8
Rows-n Gap inch 2-1/16 2-1/16
Coil Length (LXDXW) inch 33 5/16X1 3/4X26 33 5/16X1 3/4X26
Fan Motor Speed rpm 800 800
Output of Fan Motor W 60 60
Fan Motor RLA A 0.365 0.365
Fan Motor Capacitor μF / /
Air Flow Volume of Outdoor Unit CFM 1883 1883
Fan Type Axial-ow Axial-ow
Fan Diameter inch Φ20 1/2 Φ20 1/2
Defrosting Method / Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IP24 IP24
Permissible Excessive Operating
Pressure for the Discharge Side
ISPG 623 623
Permissible Excessive Operating
Pressure for the Suction Side
ISPG 362 362
Sound Pressure Level (H/M/L) dB (A) 59/-/- 59/-/-
Sound Power Level (H/M/L) dB (A) 69/-/- 69/-/-
Dimension (WXHXD) inch 38X27 9/16X15 5/8 38X27 9/16X15 5/8
Dimension of Carton Box (LXWXH) inch 40 3/8X17 7/8X29 40 3/8X17 7/8X29
Dimension of Package (LXWXH) inch 40 1/2X18X29 1/2 40 1/2X18X29 1/2
Net Weight Ib 103.6 110.3
Gross Weight Ib 113.6 120.2
Refrigerant R410A R410A
Refrigerant Charge oz 56.45 65.25
Connection
Pipe
Length ft 24.6 24.6
Gas Additional Charge oz/ft 0.5 0.2
Outer Diameter Liquid Pipe inch Φ1/4 Φ1/4
Outer Diameter Gas Pipe inch Φ5/8 Φ5/8
Max Distance Height ft 32.8 32.8
Max Distance Length ft 82 82
Note:The connection pipe applies metric diameter.
The above data is subject to change without notice; please refer to the nameplate of the unit.
