Outdoor Unit
Model of Outdoor Unit GWC36LB-D3NNB2A/O
Outdoor Unit Product Code CA433W00800
Compressor Manufacturer/Trademark
SHANGHAI HITACHI ELECTRICAL APPLIANCES
CO.;LTD.
Compressor Model ATH290RN-C9LU
Compressor Oil Mineral Oil
Compressor Type Rotary
L.R.A. A 64
Compressor RLA A 13.7
Compressor Power Input W 3020
Overload Protector UP14SE5215
Throttling Method Capillary
Operation temp ºC 16~30
Ambient temp (cooling) ºC 18~43
Ambient temp (heating) ºC /
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7.94
Rows-n Gap mm 2.5-1.5
Coil Length (LXDXW) mm 953X57.15X748
Fan Motor Speed rpm 780
Output of Fan Motor W 90
Fan Motor RLA A 0.8
Fan Motor Capacitor μF 4
Air Flow Volume of Outdoor Unit m
3
/h 4000
Fan Type Axial-ow
Fan Diameter mm Φ552
Defrosting Method /
Climate Type T1
Isolation I
Moisture Protection IP24
Permissible Excessive Operating Pressure for the
Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure for the
Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 58/-/-
Sound Power Level (H/M/L) dB (A) 68/-/-
Dimension (WXHXD) mm 980X790X427
Dimension of Carton Box (LXWXH) mm 1080X485X840
Dimension of Package (LXWXH) mm 1083X488X855
Net Weight kg 68
Gross Weight kg 73
Refrigerant R410A
Refrigerant Charge kg 2.4
Connection
Pipe
Length m 5
Gas Additional Charge g/m 15
Outer Diameter Liquid Pipe mm Φ6
Outer Diameter Gas Pipe mm Φ19
Max Distance Height m 10
Max Distance Length m 30
Note:The connection pipe applies metric diameter.
The above data is subject to change without notice; please refer to the nameplate of the unit.
