Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Model GWH07AGAXB-K6DNA1A GWH09AGCXB-K6DNA1A
Product Code CB385012200 CB385012100
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity W 2250 2650
Heating Capacity W 2700 3200
Cooling Power Input W 600 575
Heating Power Input W 720 745
Cooling Current Input A 3.1 2.95
Heating Current Input A 3.8 3.95
Rated Input W 1250 1350
Rated Cooling Current A 4.9 5.65
Rated Heating Current A 5.65 6
Air Flow Volume m
3
/h 520/470/450/420/310/290/250 740/630/560/490/420/390/360
Dehumidifying Volume L/h 0.6 0.8
EER W/W 3.75 4.6
COP W/W 3.75 4.3
SEER W/W / 4.3
HSPF W/W / /
Application Area m
2
10-16 12-18
Indoor Unit
Model GWH07AGAXB-K6DNA1A/I GWH09AGCXB-K6DNA1A/I
Product Code CB385N12200 CB385N12100
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Φ93X505 Ф98×630
Cooling Speed r/min 1300/1200/1120/1050/920/800/750 1350/1200/1100/1000/850/750/650
Heating Speed r/min 1300/1200/1120/1050/950/850/800 1200/1100/1040/950/900/880/850
Fan Motor Power Output W 20 15
Fan Motor RLA A 0.22 0.22
Fan Motor Capacitor μF 1 /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5 Ф5
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length (LXDXW) mm 509×22.8×266.7 634×22.8×304.8
Swing Motor Model MP24AK MP24BA MP24HF MP24HF MP24AK MP24BA
Swing Motor Power Output W 1.5/1.5/1.5 1.5 1.5 1.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A)
Cooling:39/36/34/32/28/23/22
Heating:39/36/33/31/29/25/23
Cooling:42/37/36/32/28/24/20
Heating:39/36/33/31/29/28/27
Sound Power Level dB (A)
Cooling:55/52/50/48/44/39/38
Heating:55/52/49/47/45/41/39
Cooling:57/52/51/47/43/39/35
Heating:57/52/49/47/45/44/43
Dimension (WXHXD) mm 704×260×185 825×293×196
Dimension of Carton Box (LXWXH) mm 748×316×247 870×349×257
Dimension of Package (LXWXH) mm 753×332×258 875×365×268
Net Weight kg 7.5 9.5
Gross Weight kg 9 11.5
