5HPRYDO3URFHGXUH
2
3
O-Gasket sub-assy of Bearing
Step
Procedure
Remove cross flow fan blade and motor.
Remove connection screws between
cross flow fan blade and motor shaft.
Then remove motor.
Remove holder of bearing ring and then
remove connection screws fixing step
motor. Then remove step motor.
cross flow fan blade
motor
step motor
