Gree GWH09NA-K3NNB1C User Manual


5HPRYDO3URFHGXUH
4. Remove front grille
Remove connection screws between the front
grille and the front panel. Then remove the front
grille.
Remove connection screws connecting the front
panel with the chassis and the motor support,
and then remove the front panel.
Remove connection screws connecting the
right side plate with the chassis, the valve
support and the electric box. Then remove
the right side plate.
Remove the nut on the blade and then remove
the axial flow blade.
5. Remove front panel
front grille
6. Remove right side plate
front panel
right side plate
7. Remove axial flow blade
axial flow blade
