Part CodeDescription
GWH09MB-K3DNE3G/I GWH12MB-K3DNE3G/I
NO.
Product Code CB404N03600 CB404N03500
Qty
1 Front Panel 2001288801P 2001288801P 1
2 Display Board 30565144 30565144 1
3 Filter Sub-Assy 1112220403 1112220403 2
4 Electric Box Cover2 2010249602 2010249602 1
5 Screw Cover 242520172 242520172 1
6 Front Case Sub-Assy 2001213923 2001213923 1
7 Axile Bush 1054203602 1054203602 1
8 Guide Louver 1051215701 1051215701 1
9 Air Louver 1 1051215601 1051215601 1
10 Air Louver 2 1051215501 1051215501 1
11 Helicoid tongue 2611216301 2611216301 1
12 Left Axile Bush 10512037 10512037 1
13 Rear Case assy 2220210311 2220210311 1
14 Cross Flow Fan 10352017 10352017 1
15 O-Gasket sub-assy of Bearing 7651205102 7651205102 1
16 Ring of Bearing 26152022 26152022 1
17 Drainage hose 0523001401 0523001401 1
18 Wall Mounting Frame 01252021 01252021 1
19 Evaporator Assy 01002424 01002953 1
20 Evaporator Support 24212091 24212091 1
21 Cold Plasma Generator Sub-assy 1114001602 1114001602 1
22 Connecting Cable 4002052317 4002052317 0
23 Power Cord / / /
24 Pipe Clamp 2611216402 2611216402 1
25 Fan Motor 150120874 150120874 1
26 Motor Press Plate 26112161 26112161 1
27 Rubber Plug (Water Tray) 76712012 76712012 1
28 Step Motor 1521212901 1521212901 1
29 Crank 10582070 10582070 1
30 Electric Box Assy 10000200890 10000200891 1
31 Electric Box 2011208201 2011208201 1
32 Terminal Board 42011233 42011233 1
33 Shield cover of Electric Box sub-assy 01592073 01592073 1
34 Electric Box Cover1 22242135 22242135 1
35 Capacitor CBB61 33010747 33010747 1
36 Jumper 4202300106 4202300105 1
37 Ambient Temperature Sensor 390000453 390000453 1
38 Main Board 30138000410 30138000410 1
39 Temperature Sensor 390000599 390000599 1
40 Remote Controller 305100491 305100491 1
Above data is subject to change without notice.
