3
Technical Information
Service Manual
The above data is subject to change without notice; please refer to the nameplate of the unit.
Outdoor
Unit
Model of Outdoor Unit GWH09MB-K3DNE3G/O GWH12MB-K3DNE3G/O
Product Code of Outdoor Unit
CB404W03600/CB404W03601
CB404W03500/CB404W03501
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD.
ZHUHAI LANDA COMPRESSOR
CO., LTD.
Compressor Model QXA-A091zE190A QXA-A091zE190A
Compressor Oil FVC 68EP FVC 68EP
Compressor Type Rotary Rotary
L.R.A. A 16.5 16.5
Compressor RLA A 4.9 4.9
Compressor Power Input W 950 950
Overload Protector 1NT11L-6233 1NT11L-6233
Throttling Method Electron expansion valve Electron expansion valve
Operation temp ºC 16~30 16~30
Ambient temp (Cooling) ºC -15~48 -15~48
Ambient temp (Heating) ºC -15~24 -15~24
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Rows-n Gap
mm 1-1.4
2-1.4
Coil Length (LXDXW) mm 710X19.05X508 695X38.1X506
Fan Motor Speed rpm 900/650 900/650
Output of Fan Motor W 30 30
Fan Motor RLA A 0.15 0.15
Fan Motor Capacitor μF / /
Air Flow Volume of Outdoor Unit m
3
/h 1600 1600
Fan Type Axial-ow Axial-ow
Fan Diameter mm Φ400 Φ400
Defrosting Method Automatic Defrosting Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IP24 IP24
Permissible Excessive Operating Pressure
for the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure
for the Suction Side
MPa 2.5 2.5
Sound Pressure Level (H/M/L) dB (A) 51/-/- 53/-/-
Sound Power Level (H/M/L) dB (A) 63/-/- 63/-/-
Dimension (WXHXD) mm 776X540X320 776X540X320
Dimension of Carton Box (LXWXH) mm 848X360X580 848X360X580
Dimension of Package (LXWXH) mm 851X363X595 851X363X595
Net Weight kg 28.0 29.0
Gross Weight kg 32.0 33.0
Refrigerant R410A R410A
Refrigerant Charge kg 0.7 0.85
Connectio
n Pipe
Length m 5 5
Gas Additional Charge g/m 20 20
Outer Diameter Liquid Pipe mm Φ6 Φ6
Outer Diameter Gas Pipe mm Φ9.52 Φ9.52
Max Distance Height m 10 10
Max Distance Length m 15 15
Note: The connection pipe applies metric diameter.
