12
Indoor Unit
Parts name
Display
NOTE
●
●
This is the general introduction and the color of indicator is only for reference. Please refer to the actual
display.
Display content may be different from the actual. Please refer to the actual display.
If remote controller is lost or damaged, please use aux. button to turn on or turn off the air
conditioner. The operation in details is as below: As shown in the figure, open panel and
press aux. button to turn off the air conditioner. When the air conditioner is turned on, it will
operate under auto mode.
aux. button
filterair inlet panel
horizontal louver
air outlet
Temp. indicator
Dry mode
Power indicator
Heat mode
Cool mode
R
(only for heat model)
R:red indicator
W:white indicator
W
G
O
G:green indicator
O:orange indicator
