7
COMPONENT SUMMARY
INDOOR UNIT
OUTDOOR UNIT
Front Panel Display
1 Front panel
2 Upper airow deector
3 Lower airow deector
4 Air outlet
5 Air inlet
6 Display (see below)
7 Dust lter
8 Directional louvers (inside)
9 Emergency button
11 Temperature indicator
12 Power indicator
1 2 7 83 4
6 95
11
12
13 Air inlet
14 Air outlet
15 Wiring cover
16 Valve cover
17 Gas valve
18 Liquid valve
14 15
16
17
18
13
NOTE : The above illustrations are only intended to be simplied representations of the appliance and
may not reect the exact appearance of the product purchased.
NOTE : The content of
the display and the colours
and shapes of the indica-
tors may vary. Please refer
to the actual display.
