MD22/ Translation of the original instructions
WARRANTY
The guarantee is given in compliance with the current law. The dealer will have to give the client a copy
of the registration card of the machine, which they will print up from the Grillo website.
For the engine the guarantee of the relative manufacturers apply.
RECOMMENDED LIST OF SPARE PARTS TO BE KEPT IN STORE
2 x mowing blades
2 x blade screws
2 x blade screw nuts
1 x set of belts
1 x air filter for engine
1 x oil filter for engine
1 x throttle cable
2 x system fuses
TECHNICAL SPECIFICATIONS
ENGINE: B&S INTEK 7220 PROFESSIONAL SERIES OHV 22 HP (16,2 kW), 656 cm³ @ 3300 r.p.m.,
twin-cylinder, petrol.
STARTER: electric with 12V battery.
FUEL TANK: 13 litres RESERVE: 3 litres
HOURLY CONSUMPTION: 4,6 litri/h.
GEARBOX: hydrostatic transmission.
DIFFERENTIAL: with lock device.
STEERING RADIUS: 38 cm
CLUTCH: electromagnetic with P.T.O and with blade brake.
SPEED: from 0 to 9 km/h with continuous variation and reverse from 0 to 6 km/h.
TYRES front: 13×5.00-6 rear: 18×8.50-8 GARDEN wheels.
BRAKE: front emergency brake and rear parking brake.
SEAT: sprung and adjustable.
CUTTING DECK: with rear discharge and mulching.
CUTTING SYSTEM: rotating with 3 blades.
CUTTING WIDTH: 110 cm (±51'')
CUTTING HEIGHT: from 30 to 90 mm (from ± 1.2'' to ± 3.5'') with 4 different cutting positions and 1
transfer position.
HOURLY CUTTING CAPACITY: approx. 8500 m²/h (± 2 acres per hour).
SIZES: Length > 1800 mm (± 71'') – Width > 1320 mm (± 52'') – Height > 1070 mm (± 42.1'')
WEIGHT: 325 kg (± 716 lb)
7
