Groen HH/4 User Manual

OM-HH
19
Parts List
Key Description Part No. Key Description Part No.
1 ¼”-20 Cap Nut 005471 37 Removable Strainer c” holes 009040
2 Handle Assy (includes items 3 & 4) 047714 for optional 1½” Draw-Off
3 Knob 012691 Removable Strainer c” holes 013785
4 Spacer 002378 for standard 2” Draw-Off
5 Hinge Bar 061012 38 Strainer w/o holes for 1½” Draw-Off 009057
6 Cover Hinge Bracket 013485 Strainer w/o holes for 2” Draw-Off 013783
7 Tolerance Ring 012692 39 Gas Pilot Burner 002457
8 Indicator Light Assembly 002986 40 ¾” Gas Valve (built after 11/88) 097001
9 ¾” IPS x 4½“ Nipple 005560 ¾’ Gas Valve (built before 12/88) 002487
10 ¼” IPS Gas Valve 002485 41 Hinge Cover LH (Prior to 5/10/84) 002293
11 Pressure Gauge 099156 42 Half Hinge LH (Prior to 5/10/84) 012878
12 Warrick Electrode 074665 43 ¾” IPS St. El 009347
13 Rubber Boot 010390 44 ¾” x ¼” x ¾” Reducing Tee 008716
14 Pressure Limit Control 096963 45 ¾” IPS x 3½” Long Nipple 008716
15 Thermostat 012313 46 ¾” 90 Degree El 008124
16 Thermostat Knob 012314 47 ¾” x 3" Long IPS Nipple 008239
17 Flue Assy Box, HH Kettles 004951 48 Gas Pressure Regulator 101570a
18 ¾” IPS 90º El (Built before 8/1/92) 010668 49 ¾” x 2½” Long Nipple 005559
¾” IPS 90º El (Built after 8/1/92) 096905 50 ¾” Gas Valve 002484
19 Water Fill Assy (Built before 8/1/92) 013541 51 ½” Gauge Glass Connector 004071
Water Fill Assy (Built after 8/1/92) 097010 52 Rubber Gauge Glass Gasket 008917
20 Safety Valve (Built before 8/1/92) 004010 53 Washer w/Assy #4071 N/A
Safety Valve (Built after 8/1/92) 097009 54 Hex Nut w/Assy #4071 N/A
21 Not Used N/A 55 Water Gauge Glass 008742
22 Not Used N/A 56 Not Used N/A
23 Toggle Switch 006904 57 Gas Valve (Prior to 6/89) N/A
24 Warrick Relay (115 Volt) 010412 Gas Valve (Built after 5/89) 079803
25 Wing Nut #10-24 009028 58 Close Nipple ½” IPS 008877
26 Valve Handle 009029 59 Reducing El ¾” x ½” x 90 Degrees 008751
27 Sanitary Hex Nut #1314 008911 60 Nipple ¾” IPS x 4" Long 005523
28 Rubber “O” Ring 009034 61 Union Elbow ¾” IPS x 4" Long 005493
29 Valve Bonnet 009024 62 Sensing Probe w/Kanthol 003328
30 Valve Stem 009027 63 Not Used N/A
31 Optional 1½” Draw-Off Valve 009000 64 Nipple ¾” IPS x 4" Long 005523
32 Burner with Jets 004825 65 ¾” IPS Gas Valve 008172
33 Slotted Cap for Item 32 (not shown) 004826 66 Pilot Burner and Electrode 003750
34 Not Used N/A 67 Sensing Probe Lead 003329
35 Not Used N/A 68 Half Hinge RH (prior to 5/10/84) 012877
36 Removable Strainer ¼” holes 009007 69 Hinge Cover RH (prior to 5/10/84) 002292
for optional 1½” Draw-Off 70 Not Used N/A
Removable Strainer ¼” holes 009044 71 Union ¾” IPS 005516
for standard 2" Draw-Off
NOTE: HH/4 and HH/4/E use natural gas only.
