Growatt MIN 5000TL-X User Manual

Index
1 Notes on this manual
2 Safety
3.1 TL-X Overview
3.2 Type label
3.3 Size and weight
3.4 Storage of Inverter
3.5 The advantage of the unit
2.1 Intended Use
2.2 Qualification of skilled person
2.3 Safety instruction
2.4 Assembly Warnings
2.5 Electrical Connection Warnings
2.6 Operation Warnings
1.1 Validity
1.2 Target Group
1.3 Additional information
1.4 Symbols in this document
1.5 Glossary
3 Product Introduction
4 Unpacking and inspection
5 Installation
5.1
5.2
5.3
Safety instructions
Selecting the installation location
Mounting the Inverter

Growatt MIN 5000TL-X Specifications

General

Purpose	Solar panel
Efficiency	98.4 %
Noise level	35 dB
Output power	5000 W
Input current	22.7 A
Input voltage	80 - 500 V
Output voltage	180 - 280 V
Input frequency	50/60 Hz
Power supply type	Indoor
Power current type	DC1-to-DC2
Maximum input power	7000 W
Maximum input voltage	500 V
Nominal output voltage	230 V
International Protection (IP) code	IP65
Display type	OLED
Product color	White
Built-in display	Yes
Quantity per pack	1 pc(s)
Operating temperature (T-T)	-25 - 60 °C

Weight and Dimensions

Depth	160 mm
Width	375 mm
Height	350 mm
Weight	10800 g
