Haier 15F6B User Manual

Position of Keys and Plug-ins
Front and side panel
15F6B
Signal receiver
Power
indicator
Power switch
VIDEO
Menu
TV/AV switch
Volume down/up
Channel down/up
AUDIOHEADPHONE
Menu
TV/AV switch
Volume down/up
Channel down/up
AUDIO R/LHEADPHONE VIDEO
Power switch
Signal receiver
Power
indicator
HT-3768
Video input terminal
Audio input terminal
Power
indicator
Signal
receiver
Menu
TV/AV
switch
Volume
up/ down
Channel position
up/down
Power
switch
Back panel
Antenna input socket
Video Cr input terminal
Audio left channel input terminal
Audio right channel input terminal
Audio left channel output terminal
Audio right channel output terminal
Video Cb input terminal
Video Y input terminal
Video input terminal
Video output terminal
S-VIDEO input terminal
ÒôƵ×óÉùµÀÊä³ö¶Ë×Ó
ÒôƵÓÒÉùµÀÊäÈë¶Ë×Ó
ÒôƵ×óÉùµÀÊä³ö¶Ë×Ó
ÒôƵ×óÉùµÀÊä³ö¶Ë×Ó
Note: Please do not use the side(front) and back AV terminals simultaneously.
21FA12/21SF1N
Note: The audio channel in some models does not have the function of stereo.
S-VIDEO and AV output terminals are only available in some models.
The terminals above are just for reference, please see the real.

Haier 15F6B Specifications

General

Brand	Haier
Model	15F6B
Category	TV
Language	English
