8 31-5000564 Rev. 1

ENGLISH

Required Tools for Installation

• 14/4 AWG stranded wire

• 5/8” (16mm), 7/8” (22mm), 1” (25mm) or Adjustable

Wrench

• R-410A Refrigerant*

• Adhesive tape*

• Conduit cable clamp 1/2”*

• Copper line set (for size, see table on page 15)

• #2 phillips screwdriver

• Drill

• R-410A flaring tool

• Hex wrench

• Hole saw 2 1/4”

• Insulation*

• Refrigerant scale

• Level

• Manifold gauge set

• Measuring tape

• Micron gauge

• Mini-split adapter (5/16”F to 1/4”M)

• Nitrogen*

• Pipe cutter

• PVC pipe

• Razor knife

• Reamer

• Saddle clamp (L.S.) w/ screws

• Sealant, non-expanding (for lineset hole)

• Soap/water solution* or gas leakage detector

• Stud finder

• Torque wrench

• Vacuum pump

• Wire strippers

• All usual and customary HVAC hand and power tools,

meters, and testing devices

* consumable

INSTALLATION INSTRUCTIONS
