Service Manual
Model No.: 40D3505
Chapter 4. Location of Controls and Components
4-1. Board Location
13
A Board
B Panel
B
No.
Parts number
Description
A Board
DH1TK3M0100M
power-main board
B Panel
712-39583-X3250
LCD Panel
