OUTDOOR TECHNICAL OVERVIEW
B-22
ENGLISH
DIP Switch Settings
Service Monitor Board SW1 DIP Switch Settings
Outdoor Central
Control Address
SW6-1 SW6-2 SW6-3 SW6-4
Master Indoor Unit OFF OFF OFF OFF
Slave 1 ON OFF OFF OFF
Slave 2 OFF ON OFF OFF
Slave 3 ON ON OFF OFF
Slave 4 OFF OFF ON OFF
Slave 5 ON OFF ON OFF
Slave 6 OFF ON ON OFF
Slave 7 ON ON ON OFF
Slave 8 OFF OFF OFF ON
Slave 9 ON OFF OFF ON
Slave 10 OFF ON OFF ON
Slave 11 ON ON OFF ON
Slave 12 OFF OFF ON ON
Slave 13 ON OFF ON ON
Slave 14 OFF ON ON ON
Slave 15 ON ON ON ON
Outdoor central control address settings
Definition SW1-1 SW1-2 SW1-3 SW1-4
Default From Factory (Normal Operations) OFF OFF OFF OFF
Forced Heating ON OFF OFF OFF
Forced Cooling OFF ON OFF OFF
Rated Condition Operations (Factory Testing) OFF OFF ON OFF
Set Enhanced Defrost OFF OFF OFF ON
Wiring Error Check* ON ON ON ON
Description SW7-1 SW7-2 SW7-3 SW7-4 SW7-5 SW7-6 SW7-7 SW7-8
3U24GS1ERE & 3U24MS2VHB OFF OFF OFF OFF OFF OFF ON OFF
4U36HS1ERE & 4U36MS2VHB OFF OFF OFF OFF OFF OFF ON OFF
SW6 DIP Switch Settings
SW7 DIP Switch Settings: Conī©guration
*See page B-17 for Wiring Error Check.
***All other combinations are for use in other regions***
