8. Dip switch setting
Operate according to the following setting as necessary after refrigerant piping construction and electrical wiring
construction are nished.
1. Code setting for the address of wired control and the capacity of connection kit:
1 is ON, 0 is OFF
2. Code setting for the postal address of the connection kit:
SW2 is used for AH devices address setting, 1 is ON, 0 is OFF
SW3_1
~
SW3_4
Wired Indoor
Address
[1] [2] [3] [4] Wired Indoor Adress
0 0 0 0 0# Slave Unit (Default)
0 0 0 1 1# Slave Unit
0 0 1 0 2# Slave Unit
… … … … ……
1 1 1 1 15# Slave Unit
SW3_5
~
SW3_8
AHU
Capacity
[5] [6] [7] [8] AHU Capacity
0 0 0 0 /
0 0 0 1 /
0 0 1 0 /
0 0 1 1 /
0 1 0 0 /
0 1 0 1 /
0 1 1 0 /
0 1 1 1 AH1-070B
1 0 0 0 /
1 0 0 1 /
1 0 1 0 /
1 0 1 1 AH1-140B
1 1 0 0 /
1 1 0 1 /
1 1 1 0 AH1-280B
1 1 1 1 AH1-560B/AH1-730B
SW2_1
Manner of set
address
0 Set the address with automatism
（
default
）
1 Set the address with dip switch
SW2_2
~
SW2_8
The
communication
address of rst
indoor unit
address
[2] [3] [4] [5] [6] [7] [8]
Communication
address
Center controller
address
0 0 0 0 0 0 0 0#
（
default
）
0#
（
default
）
0 0 0 0 0 0 1 1# 1#
0 0 0 0 0 1 0 2# 2#
0 0 0 0 0 1 1 3# 3#
0 0 0 0 1 0 0 4# 4#
0 0 0 0 1 0 1 5# 5#
0 0 0 0 1 1 0 6# 6#
0 0 0 0 1 1 1 7# 7#
