1.3 System lineup
1.4 Conguration
1.5 Nomenclature
Code
position
1
，
2 3 4 5 6
7 8
Code
meaning
Valve box series Valve box type
Space
mark
Indoor capacity which Valve box can be
connected
Series number
Code and
contents
VP
3-pipe valve
box
1 1 to 1
-
Cooling
capacity
Cooling
capacity<
99KW
Three digits***(unit
：
100W)
A
First
generation
MS
MRV
+SUPER
MATCH
valve box
2 1 to 2
Cooling
capacity
Cooling
capacity>
99KW
Three digits 000
（
unit
：
HP)
B
Second
generation
AH
MRV + AHU
valve box
3 1 to 3
Cooling
capacity
Cooling
capacity is
not dened
Three digits 000 C
Third
generation
4 1 to 4
… …
… …
… …
Haier AHU kit provides a wide range solution for Haier MRV outdoor unit connecting with the 3rd party AHU
Compatibility
Outdoor MRV5 MRV SII
HP 8-26 4 5 6 8 10 12
Power Supply
3Ph/380-
415V/50/60Hz
1Ph/220-230Ph/50/60Hz
3Ph/380-400V/50/60Hz
3Ph/380-400V/50/60Hz
AH1-070B/AH1-140B/AH1-280B
AH1-560B/AH1-730B
